Description
Fire rated (90min) and sealed LED downlight complete with triac dimmable driver.
Tested in both conventional timber and I-joist ceilings.
White finished body with silver baffle and clear safety glass.
| Cat no. | Colour | LED | Lumens | Watts | Beam |
|---|---|---|---|---|---|
| F690/S3/WH | White | 3000K | 1000 | 9.5 | Flood |
Also available to order
| Cat no. | Colour | LED | Lumens | Watts | Beam |
|---|---|---|---|---|---|
| F690/S3/WH/2700 | White | 2700K | 900 | 9.5 | Flood |
| F690/S3/WH/4000 | White | 4000K | 1000 | 9.5 | Flood |
IP65
Electrical class 2 (double insulated)
62mm OA dia x 90mm deep Cut-out 52mm dia.
Add suffix /EL to Cat no for 3 hour self-contained maintained emergency version.
LED charge indicator 25mm OA dia x 25mm recessed depth Cut-out 20mm dia. (mounted separately)
This downlight is supplied pre-wired to driver and fitted with 300mm 2-core flying lead for connection to 240v supply.
